Wired Lav Mics
Audio Technica AT803 - $199 - in stock
The AT803 provides excellent yet unobtrusive sound pickup for
video production, lecturers and stage/TV performers. Designed for
clip-on lavalier and musical instrument use, it features an integral
80 Hz high-pass filter that provides easy switching from a flat
frequency response to a low-end roll-off. The microphone operates
on battery or phantom power.
Features
* High intelligibility for lecturers and stage/TV performers
* Provides excellent yet unobtrusive sound pickup
* UniSteep® filter provides a steep low-frequency attenuation
to improve sound pickup without affecting voice quality
* Operates on battery or phantom power
* 6' (1.8 m) cable permanently attached to mic, TA3F connector
at power module
* RoHS compliant—free from all substances specified in the
EU directive on hazardous substances
Specifications
* Element: Fixed-charge back plate, permanently polarized condenser
* Polar Pattern: Omnidirectional
* Frequency Response: 30 - 20,000 Hz
* Low Frequency Roll-Off: 80 Hz, 12 dB/octave
* Open Circuit Sensitivity: Phantom: -44dB (6.3 mV) re 1V at 1Pa;
Battery: -46 dB (5.0 mV) re 1V at 1 Pa
* Impedance: Phantom: 200 ohms; Battery: 270 ohms
* Maximum Input Sound Level: Phantom: 135 dB SPL, 1kHz at 1% T.H.D.;
Battery: 121 dB SPL, 1 kHz at 1% T.H.D.
* Dynamic Range (typical): 107 dB, 1 kHz at Max SPL; Battery: 93
dB, 1 kHz at Max SPL
* Signal-to-Noise Ratio: 66 dB, 1kHz at 1 Pa
* Phantom Power Requirements: 11-52V DC, 2 mA typical
* Battery Type: 1.5V AA/UM3
* Battery Current/Life: 0.4 mA/1200 hours typical (alkaline)
* Switch: Off, on-flat, on-roll-off
* Weight, Microphone: 0.1 oz
* Weight, Power Module: 4.9 oz
* Dimensions, Microphone: 0.98" Length x 0.40" Diameter
* Dimensions, Power Module (H x W x D): 3.31" x 2.48" x
0.87"
* Output Connector: Integral 3-pin XLRM-type
* Cable: 6' long (permanently attached to microphone), 0.10" diameter,
2-conductor, shielded cable with TA3F-type connector
* Accessories Furnished: AT8531 power module; AT8417 clothing clip;
AT8116 windscreen; battery; protective carrying case
|
